New BIOS from Asrock rocks. :cool: Updated BIOS to 1.18AS04 ComboAM5 1.0.0.5c. Older 1.0.0.4 BIOS takes min 33-40 secs for cold/hot reboot before monitor turn on. New BIOS takes on average 8 secs with min value ~5 secs but is very rare.

People with Asrock and GSkill Flare X5 6000 which uses Richtek PMIC should come out from the shadow and do your testing again. It unlocks the high voltage mode!! :D
Either CL28 or tRCD36 used to error out within minutes at 1.43v, currently set to 1.48v in BIOS and testing fine at both CL28 and tRCD36.

High voltage 1.48v Flare X5 Richtek PMIC.png

  • Like
  • Love
Reactions: lightmanek, Tlh97, alexruiz and 2 others
Upvote 1 Downvote
S

SK10H

Member
Jun 18, 2015
124
57
101
I also try to do an idle / light load test and see how the Eco PBO 65W mode compare to the good old static 1.025v 4.8Ghz cool and quiet mode. I try to make it as fair as possible on both idle and light load test by not doing anything else. Both obviously include the capturing software usage, so probably not so fair to the PBO side.


Idle* Test

The Eco mode simply cap the PPT as it makes no attempt to lower the overvolted 1.3-1.4 vcore when core speed is only in the 1-4Ghz range. It usually burn 15-25W CPU power. I don't know if it's a limitation because it may degrade the cpu quickly if AMD set it to 1v on low speed and spike to ~1.4-1.52v quickly and repeatedly.

The manual 1.025v static 4.8GHz uses ~7-9W CPU power.



Light load test on streaming quote from Tradingview on 1 Chrome window only

The Eco mode light load test use ~28W on avg, spike to ~46W max CPU power.

The manual 1.025v static 4.8GHz use ~9-12W on avg, spike to 18W max CPU power.



Using Asrock Blazing OC Tuner 1.04 to test, the feature is a bit limited. Although I can set either static OC or PBO mode manually, it does not provide a way to set this by schedule to define how it would run automatically. Also it would have been excellent if I can just right click on systray and select the OC or PBO mode easily instead of opening it up like this.

Since I use this as a 24/7 server/vm/gaming comp, it seems to be more efficient to just set static OC manually most of the time, forget about Eco mode, and only turn on PBO mode through the App when gaming.

  • Like
Reactions: inf64, lightmanek, Tlh97 and 2 others
Upvote 2 Downvote
biostud

biostud

Lifer
Feb 27, 2003
18,604
5,300
136
  • Like
  • Wow
Reactions: lightmanek and igor_kavinski
Upvote 0 Downvote
moinmoin

moinmoin

Diamond Member
Jun 1, 2017
5,063
8,025
136
In2Photos said:
He said that sometimes the memory doesn't initialize when you enable fast boot.
Click to expand...
Sounds like fast boot should make sure memory is already initialized before handing over to the OS. (This makes it sound like there were parts being reinvented for little reason. Isn't this being done already anyway?)

Upvote 0 Downvote
Hail The Brain Slug

Hail The Brain Slug

Diamond Member
Oct 10, 2005
3,474
2,395
136
biostud said:
Anyone else have updated to 1.0.0.5c?
Click to expand...

Updated to it on my X670E Aorus Master. All my previous settings working fine.

I was hoping to see the Cache/memory analysis feature that was shown in the ASUS 1.0.0.5C update, but I see nothing of the sort. At this point unsure if ASUS exclusive feature or if it's just hidden without an X3D CPU installed.

  • Like
Reactions: lightmanek
Upvote 0 Downvote
In2Photos

In2Photos

Golden Member
Mar 21, 2007
1,945
1,980
136
Justinus said:
Updated to it on my X670E Aorus Master. All my previous settings working fine.

I was hoping to see the Cache/memory analysis feature that was shown in the ASUS 1.0.0.5C update, but I see nothing of the sort. At this point unsure if ASUS exclusive feature or if it's just hidden without an X3D CPU installed.
Click to expand...
Do you save your settings to a flash drive and then import them or manually change them each time?

Upvote 0 Downvote
Hail The Brain Slug

Hail The Brain Slug

Diamond Member
Oct 10, 2005
3,474
2,395
136
In2Photos said:
Do you save your settings to a flash drive and then import them or manually change them each time?
Click to expand...

Doesn't seem to be a way to save a bios profile on my gigabyte board (at least not that I could find in the UEFI or in the manual) so I have to re-enter everything every time.

They do allow saving of fan profiles, but those didn't work across this last update to 1.0.0.5C so I had to re-enter the fan profiles by hand as well.

o_O

Upvote 0 Downvote
AdamK47

AdamK47

Lifer
Oct 9, 1999
15,489
3,199
136
I'll update my Asus ROG X670E Extreme to 0922 tonight. I'll save off my settings from 0902 to USB and import them. Won't use CO values afterwards since every AGESA is different.

Upvote 0 Downvote
J

JoeRambo

Golden Member
Jun 13, 2013
1,814
2,105
136
Justinus said:
Doesn't seem to be a way to save a bios profile on my gigabyte board (at least not that I could find in the UEFI or in the manual) so I have to re-enter everything every time.
Click to expand...

There is one, in advanced mode menu, of saving. Compared to MSI it even works between BIOS versions, i was very surprised it did.


EDIT: At least on B650M Aorus Elite Ax, the unbreakable retarded streak of borked AMD BIOS'es continues. After reboot HWinfo64 is missing all MB related items like Fan Speeds etc. Obviuosly Fan Control does not work either. Proud of those guys and their testing.
EDIT2: C-States also broken, CPU can't go lower than C1 and lovely burns the power @35W idle.

Last edited:
  • Like
Reactions: lightmanek
Upvote 0 Downvote
J

JoeRambo

Golden Member
Jun 13, 2013
1,814
2,105
136
In2Photos said:
Is 1.0.0.5C Beta for you guys with Asus, ASRock, and Gigabyte boards? It is for MSI.
Click to expand...

Mine was not beta, but completely unworkable, returned back to F3h on B650M Aorus Elite ax.

Everything working just great on trip back, including loading the profile from M.2 drive partition. They have this part of solution figured out.

  • Like
Reactions: lightmanek
Upvote 0 Downvote
Hail The Brain Slug

Hail The Brain Slug

Diamond Member
Oct 10, 2005
3,474
2,395
136
JoeRambo said:
There is one, in advanced mode menu, of saving. Compared to MSI it even works between BIOS versions, i was very surprised it did.


EDIT: At least on B650M Aorus Elite Ax, the unbreakable retarded streak of borked AMD BIOS'es continues. After reboot HWinfo64 is missing all MB related items like Fan Speeds etc. Obviuosly Fan Control does not work either. Proud of those guys and their testing.
EDIT2: C-States also broken, CPU can't go lower than C1 and lovely burns the power @35W idle.
Click to expand...

Can you specify where the feature is in your bios? I'd like to look. I was pretty irritated when I couldn't find any way to save a UEFI config after getting the board.
