Quadrature RPM algorithm

[polarmystery]

Hey guys,

I'm having trouble coming up with an algorithm for my micro-controller to measure pulses on a timer in a quadrature decoder. What it is supposed to do is count the number of times BitRdPortI(PFDR, 0) == TRUE and record is as a rotational rate but the way I have it is incorrect. What it does now is simply count up forever while the port is TRUE.

The Quad decoder if you are unfamiliar with it counts from 0 to 3 in binary (IE: 00-> 11 and it rolls over after that) and there are two port pins that contain the changing bits. If I poll a port (let's say I use the right-most bit to count 1's), it will simply count up until it's at 0 while staying in that loop, but I need it to count all the pulses when they change (IE: if it's counting the right-most bit, it should read 2 if I cycle through all positions) until count reaches 100. Any ideas? It should be simple, but I can't put my finger on what it should be. Thanks in advance! Here is my crappy code snippet thus far:

void velocity()
{
   int count;
   count = 0;

       while(count < 100)
      {
         if (BitRdPortI(PFDR, 0) == TRUE)
          rate++;
      }
   }
   printf(" Ticks per second %d \n",rate);
   printf("\x1Bt");
}



[esun]

You want an edge detector, which requires state. The condition you want is not that X == TRUE (let X be the signal in question). Rather, you want to count up when the CURRENT value of X == TRUE and the PREVIOUS value of X == FALSE, meaning you got a rising edge. I'll let you figure out how the code for that looks.



[polarmystery]

You want an edge detector, which requires state. The condition you want is not that X == TRUE (let X be the signal in question). Rather, you want to count up when the CURRENT value of X == TRUE and the PREVIOUS value of X == FALSE, meaning you got a rising edge. I'll let you figure out how the code for that looks.

If I did that, because the code polls continuously, I'd get the same results no?



[Leros]

You should be doing this via interrupts, not polling. What chip are using?



[Colt45]

If you want to poll it, you'll need something like this

	while(count < 100)
	{
		oldstate = state;
		state = (BitRdPortI(PFDR, 0);
		if(state != oldstate) //state has changed
			rate++;
	}

This doesn't account for rising/falling, it will trigger on either, so you need to modify it a bit if you only want it on one edge.

But unless you are using some archaic thing, or badly planned your board and got stuck with a signal on a pin with no interrupts... interrupts are really the way to go here.

(ps - your loop never increases 'count', so it will never exit ... unless it's incremented in an interrupt routine.)

Or am I misunderstanding your question..? Are you trying to count pulses, or measure their length?



[William Gaatjes]

If you are using a quadrature encoder, then what you have is that on the rising edge of one pin, the other pin will be low or high depending on the direction.
The easiest way in software is to indeed use an interrupt for this. The interrupt triggers on the rising edge. And in the interrupt service routine you count the amount of interrupts you had (just +1); and you check the level of the other pin to find out the direction. For example clockwise can be a high level and counter clockwise can be a low level. Then you can use averaging filters (in software) to filter out glitches if needed. This last sentence sounds difficult but it is just using variables as counters and checking these counters on a fixed repetition period for a certain threshold value.

If you insist on not using an interrupt, you are best of to use a little bit of hardware. A so called D-flipflop will store the direction for you. An averaging algorithm polling the clk input pin (which is also connected to the quadrature encoder)of the d flipflop will determine an averaged but rough count. The output of the flipflop will hold directional information in the same way as described as above. Because the output will follow the d input pin when the clk pin is experiencing a rising edge.

This is a most simple explanation where i omitted a lot of secondary information. But it will do. And give you a rough idea.


I used the hardware version once for rotary buttons with quadrature encoders in them. But i also used the interrupt version. For motor encoders, you really need interrupts or you are going to have problems determining the angle of the motor shaft...


P.S.

If you only need rpm, you need only one pin but i will let you figure it out yourself. ^_^


EDIT:

One more picture for clarity :



[polarmystery]

You should be doing this via interrupts, not polling. What chip are using?

A Rabbit 3000A. I know I should be using interrupts, but I suck coding them.

Edit: Nevermind. I got it to work. I tied an interrupt pin to one of the legs of the Quad Decoder and it worked great.

Sometimes...I need to step back and take a deep breath. I tend to freak out too much *sigh*



[polarmystery]

If you want to poll it, you'll need something like this

    while(count < 100)
    {
        oldstate = state;
        state = (BitRdPortI(PFDR, 0);
        if(state != oldstate) //state has changed
            rate++;
    }

This doesn't account for rising/falling, it will trigger on either, so you need to modify it a bit if you only want it on one edge.

But unless you are using some archaic thing, or badly planned your board and got stuck with a signal on a pin with no interrupts... interrupts are really the way to go here.

(ps - your loop never increases 'count', so it will never exit ... unless it's incremented in an interrupt routine.)

Or am I misunderstanding your question..? Are you trying to count pulses, or measure their length?

I was trying to count pulses, so I ended up using an external interrupt pin as mentioned above. It's not intuitive for me to use interrupts for some reason, but it worked great.



[Leros]

A Rabbit 3000A. I know I should be using interrupts, but I suck coding them.

Edit: Nevermind. I got it to work. I tied an interrupt pin to one of the legs of the Quad Decoder and it worked great.

Sometimes...I need to step back and take a deep breath. I tend to freak out too much *sigh*

Hahaha, it had a quadrature decoder the whole time

That's a pretty cool chip. The six SCI ports are pretty handy. I've never seen a chip with more than 2.



[Modelworks]

Hahaha, it had a quadrature decoder the whole time

That's a pretty cool chip. The six SCI ports are pretty handy. I've never seen a chip with more than 2.

I use a lot of the microchip pic chips and they have a bunch of them with quad decoders. They have a lot of chips with good features especially for motor control. This one sells for about $5 and includes everything from motor control to CAN networking for cars, to an audo DAC for sound. It is amazing what you can get for $5 now.
