Info Asus, Gigabyte and Asrock adding Vermeer and Renoir support to A320 boards. (Update: 1.2.0.7 adds Cezanne support to 300 series)

[Shivansps]

Then why allow Vermeer for A320 if Renoir was the point all along?

My best guess is that the A320/Veermer block was never in place, due to an oversight or the maybe some special motherboard with A320 that must support Veermer. And some OEMs went ahead and mentioned that. Remember that Veermer is not on all OEM A320 official CPU support list, Renoir is, i think only gigabyte list them. In short, i dont think thats intentional.

Either that or the fact that B350/X370 are EOL and A320 is not.

The question here would be is how they are actually blocking this? by chipset name or motherboard name? Because due to B350 and X370 going EOL, OEMs got rid of the remaining stock by placing them on A320 boards. Gigabyte A320M-S2H V2 is an example of a A320 board with a B350 chipset that has overcloking enabled for example. Gigabyte list Veermer as supported CPUs on that A320 board with B350 chipset so, to me, they are checking for motherboard name, not chipset ID. Someone should hack the motherboard name string and see what happens.



[.vodka]

ASUS A320 boards boot Vermeer with the new BIOSes. They're even listed in the CPU compatibility list.

Asrock's A320 boards do, too. Link to one

Biostar started distributing A320 BIOSes based on the same AGESA v2 1.2.0.3c release. Vermeer support, too.

Vermeer on A320 is not a gigabyte only thing. It is a public, not restricted to OEMs release, done so far by Asus, Gigabyte, Asrock and Biostar. MSI is probably next.People tried crossflashing these Asrock A320 BIOSes to X370 boards like the C6H, Vermeer doesn't POST. If you crossflash B450/X470 V2 1.2.0.3c BIOSes to X370 boards, Vermeer doesn't POST.


If I were to guess, the block is being done through a whitelist based on some identifier each chipset uses to identify itself, and it's defined at build time so no way to go looking around the AGESA black box to edit it. But then you'd probably break the signature and the whole thing would become an unbootable brick. This theory would be confirmed if someone were to swap, say, B350/X370 for B450/X470. They're the same silicon, so they should be pin compatible too.

The big change in the chipset will be in the power consumption. Currently the X370 chipset, built on a 55nm manufacturing process using ASMedia IP, runs at a 6.8W TDP (running at full load). For X470, we were told that this is the same process and IP, but the chip will now run at 4.8W peak and 1.9W in an idle mode. This is due to an improved power infrastructure within the chip, and AMD also claims that overall throughput is improved. The chipset firmware is also set to provide better memory OC support and stability.

Anyway, the point being is, AMD went out of their way to implement this block on AGESA V2 1.2.x.x and it's still there, in full force. Every reason they gave for not doing Zen3 on 300 series chipsets has been debunked so far, proven to be lies and excuses. They're even doing it themselves on A320 now.

I particularly like this answer to one of AMD's employees on the big reddit thread

But then comes A320 along with official, public (non OEM only) AGESA v2 support for Renoir and Vermeer (not Cezanne, doesn't POST, so that's locked) a few weeks ago and B350/X370 getting this treatment now (Renoir allowed, Vermeer and Cezanne don't POST/are locked). There's a business decision here to leave 300 series chipsets out from day one, that has turned into specifically making B350/X370 outcasts and I don't know why.

Outcasts, couldn't have put it better.

It is what it is.

Screw artificial, deliberate limitations.



[Shivansps]

The block its not chipset based. As i said, the A320M-S2H V2 wouldnt boot Veermer CPUs if that were the case, and it seems they do. It is using some other parameter, and the only thing it makes sence is the motherboard name.
Unless they are specifically whitelisting X models.

Well, what had we learn here? dont buy high end, 1st gen AM5 motherboards. The message is very clear.



[KompuKare]

I particularly like this answer to one of AMD's employees on the big reddit thread
Outcasts, couldn't have put it better.

It is what it is.

Screw artificial, deliberate limitations.

Never registered on Reddit but tempted just to join with those protesting this nonsense. PCIe 4.0 I sort of could understand (or force everyone who wanted to enable PCIe 4.0 for the M.2 to read a long statement about possible date corruption), but this is just stupid segmentation for no reason. X370 buyers were likely to have been the bigger spending early AM4 adapter too.

Then again wasn't there a brigade on Reddit defending A520 coming without PCIe 4.0 going on about the "chipset" not supporting it . the A?20 chipsets are mostly the CPU SOC and besides the PCIe 4.0 for M.2 on B550 comes directly from the CPU so the chipset has nothing to do with it. Older A320 boards where the OEM scimped on the signalling are a separate issue.



[bononos]

Seems like some manufacturers like MSI, Asus (not sure about others) are not listing Vermeer on their compatible list of cpus but are silently adding Vermeers to their supported list on A320 boards. Not sure about this but MSI might be the first one to (silently) add Vermeers to b350 boards, so other makers might follow suit.

Cezanne was probably not added because of lack of bios space, all the b350/a320 boards still support Bristol Ridge unlike b450 models which booted out BR to make room for Zen3 models.



[Shivansps]

Cezanne was probably not added because of lack of bios space, all the b350/a320 boards still support Bristol Ridge unlike b450 models which booted out BR to make room for Zen3 models.

No, the bios size limitation is a lie and always was. In fact A320 do have the Cezanne microcode in their bios, but it is just blocked from booting up. At any rate, B450 16MB boards can support everything.



[bononos]

No, the bios size limitation is a lie and always was. In fact A320 do have the Cezanne microcode in their bios, but it is just blocked from booting up. At any rate, B450 16MB boards can support everything.

B450 board do not have Bristol Ridge compatibility, the bios descriptions says that that support was dropped in the more recent bios versions to make room for Matisse and newer cpus. Not disagreeing with what you are saying about Cezanne, just that B350/A320 still supports BR but new bios's for B450 do not.

Its a good thing that MSI silently gave B350 support for Vermeer/Renoir even though they were EOL'd.



[Insert_Nickname]

B450 board do not have Bristol Ridge compatibility, the bios descriptions says that that support was dropped in the more recent bios versions to make room for Matisse and newer cpus. Not disagreeing with what you are saying about Cezanne, just that B350/A320 still supports BR but new bios's for B450 do not.

My B450-E never supported BR, so there isn't anything to remove. Likewise with my B450M-PRO S.

If you're running BR for some reason, better to just stay on a working BIOS. I doubt there is much improvement for it anyway.



[Shivansps]

B450 board do not have Bristol Ridge compatibility, the bios descriptions says that that support was dropped in the more recent bios versions to make room for Matisse and newer cpus. Not disagreeing with what you are saying about Cezanne, just that B350/A320 still supports BR but new bios's for B450 do not.

Its a good thing that MSI silently gave B350 support for Vermeer/Renoir even though they were EOL'd.

B450 never supported BR, and A320/B350/X370 are dropping BR support with the new bios. This is due to share the same agesa build as B450 boards that never supported BR to start with.

But again, it never was a bios size thing (the microcode is very small, just a few KBs, i think the entire AM4 lineup is less than 2MB). It was a bussiness decision to drop BR support starting with the 400 chipset series, and from that point on, 300 and 400 were on two diferent developments cycles, not only because of BR, they planned to just drop 300 series support for Matisse too, they had to revert that decision due to the backlash.

The 300 boards are now switching to 400 series agesa builds that has blocks in place to avoid having a combination that AMD does not want. They only really want to support Renoir with this, not sure wth happened with Veermer and A320 there.

AMD Renoirs PRO are starting to show up everywhere and in good amounts. And there is now the new Athlon based on it and the rumored Renoir-X skus whiout IGP.



[bononos]

B450 never supported BR, and A320/B350/X370 are dropping BR support with the new bios. This is due to share the same agesa build as B450 boards that never supported BR to start with.
.............

Yes, you're right, I made a wrong assumption when I read the description on a mid-2019 MSI bios update which said that BR wasn't supported and thought that BR was supported when b450 was released.



[Timorous]

Has anybody had any luck getting that B350 Tomahawk bios working on a B350M Mortar? If I can get a working vermeer BIOS for my Mortar then I am very likely to upgrade to the 5800X3D if the price is not absurd.

Edit: As for why AMD did this perhaps it is supply/demand related. If 350/370 owners could have upgraded to zen3 from the off I think the part shortages would have been even worse. Of course now there is less reason to block those chips when they are allowed to work on thr objectively inferior A320 platform.



[.vodka]

Well, this thread blew up. Good to see Tom's looking into it:

AMD: We're Exploring Supporting Ryzen 5000 on 300-Series Motherboards

Thing is, there is nothing to explore, AMD.

I see the infamous Gigabyte A320M-S2H V2 (B350 in disguise with Vermeer support because of it being "A320") got some attention too. Even The Stilt got caught up in all of that, lol

Has anybody had any luck getting that B350 Tomahawk bios working on a B350M Mortar? If I can get a working vermeer BIOS for my Mortar then I am very likely to upgrade to the 5800X3D if the price is not absurd.

I don't think anybody has tried. That B350 Tomahawk BIOS is based on AGESA v2 1.1.0.0, so it doesn't have any of the artificial locks. If the B350M Mortar is similar enough, it could work. Do you have a SPI programmer? One of those cheap CH341a programmers will do the job.

It may as well not work, for example ASUS boards get bricked if you try to use a BIOS from another model, even from the same family.



[AnitaPeterson]

I can't believe that a basic board like the Biostar A320MH (which has by now reached revision 6!) can run a 5600X, while a more expensive Fatal1ty AB350 won't be able to do it... Yet, here we are!



[Asterox]

Finally, now it's official Bios support.

ASRock releases first official X370 BIOS with Ryzen 5000 "Vermeer" support - VideoCardz.com

AMD finally allows board partners to support Ryzen 5000 on X370 motherboards? After years of waiting, AMD is finally letting board partners officially support Ryzen 5000 CPUs. The situation around AMD 300 series motherboards supporting Zen3 CPUs couldn’t be any more confusing. AMD has repeatedly...

videocardz.com

ASRock X370 Pro4

ASRock Super Alloy; Supports AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen CPUs (Summit Ridge & Raven Ridge); Supports DDR4 3200+ (OC) (Ryzen CPU) / 2400 (A-series APU); 2 PCIe 3.0 x16, 4 PCIe 2.0 x1; AMD Quad CrossFireX™; Graphics Output: HDMI, DVI-D, D-Sub; 7.1 CH HD Audio (Realtek...

www.asrock.com



[Shmee]

Very good news! I hope there are many more supported boards to come!



[Insert_Nickname]

Very good news! I hope there are many more supported boards to come!

Indeed. Hope my Crosshair VI gets the treatment.

With my Asrock AB350M Pro4 it doesn't matter too much. That thing has never been stable with any Ryzen APUs anyway. But the AGESA update is appreciated.



[Shivansps]

I wonder if AMD has a 12-year old making these decisions...

-They release Renoir and Veermer support to A320, A320 is still in production and they need to sell Renoirs, this makes sence. Yet no one stops for one second to think that they already had problems with people with flagships or very good 300 boards complaining about lacking Veermer support. You only need to stop for two seconds to realise that people is going to complain about it.

-After the complains on reddit and the bios size limitation and all their excuses proveen to be lies once again, they release Renoir only to B350/X370, what only ends up pissing people even more. Just stop to think, everyone wanted to have the same support as A320, thats NOT the same!!!!

-Now they release Veermer support to X370 only, and B350 is left aside. This looks like highschool level BS to me.

-Cezanne still locked out of the 300 series for... reasons.

Just unify everything and move on AM5, they are just pissing people off with these poor attempts at artificial segmentation.



[ElFenix]

me right now:



[Shmee]

I wonder when my Gigabyte B350M Gaming 3 gets a new update...



[ElFenix]

beta for x370 taichi leaked a month ago (might be a hack by someone outside of asrock):

Computertechnik JZelectronic

www.jzelectronic.de



[.vodka]

beta for x370 taichi leaked a month ago (might be a hack by someone outside of asrock):

Computertechnik JZelectronic

www.jzelectronic.de

Post #1 vom 09.12.2020, 10:17

That's one of the original experimental B350/X370 BIOSes (AGESA v2 1.1.0.0) Asrock put out back in December 2020, that resulted in them getting a warning from AMD.

We could've officially had Zen3 on 300 series boards back then, but AMD had to go ahead and lock things out in AGESA v2 1.1.8.0 (Zen3 release) and later 1.2.x.x based BIOSes.

Screw artificial limitations.



[Ranulf]

Nothing from Gigabyte on my AORUS GA-AX370-Gaming K7. Though I did learn they added 3000 series support in late 2019.



[bdunosk]

Thanks to all who posted info... I was hoping to drop a 5700g into my Asus B350 ROG Strix, sounds like I need to start researching Alder Lake this time around.



[.vodka]

Asrock updated some more of their X370 boards to support Renoir and Vermeer.

https://www.reddit.com/r/Amd/comments/snki0m



[Shmee]

Update here, looks like Gigabyte has released a new BIOS with Vermeer support for my B350M gaming 3 board. Yay! The version is labeled T51c, which is kind of odd. Odder still, this version is dated a couple of days before the latest F51d, and it has an earlier AGESA listed, despite claiming to support the newer CPUs, including the 5800X3D. https://www.gigabyte.com/Motherboard/GA-AB350M-Gaming-3-rev-1x/support#support-dl-bios

I may start looking for deals on a 5950X, and move the 5900X over to the B350 computer. Thoughts on this?
