Old 12-29-2012, 01:23 AM   #1
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Cool llano overdose



I delidded all those 3870's and overclocked them (cept 1 which I broke)

seems they all overclock nearly exactly the same

3.3GHz 800MHz nb is the most common
one did 720 for the nb, but would do 3.4GHz core
also I noticed the default voltage for the newest one is 1.4v instead of 1.4125
and they stopped putting the foam square under the cpu in the packaging
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org

Last edited by Soulkeeper; 12-29-2012 at 01:25 AM.
Soulkeeper is offline   Reply With Quote
Old 12-29-2012, 03:41 AM   #2
ShadowVVL
Senior Member

Join Date: May 2010
Posts: 747
Default

someone loves llano

lol photo reminds me of the setup in my old appartment with the box spring and mattress on the floor.

Any plans on getting trinity? or is there no delidding trinity?
ShadowVVL is offline   Reply With Quote
Old 12-29-2012, 07:08 AM   #3
VirtualLarry
Lifer

VirtualLarry's Avatar

Join Date: Aug 2001
Posts: 26,753
Default

Quote:
Originally Posted by Soulkeeper View Post
and they stopped putting the foam square under the cpu in the packaging
that sounds like it could be dangerous to the pins during rough shipping.
__________________
Rig(s) not listed, because I change computers, like some people change their socks.
ATX is for poor people. And 'gamers.' - phucheneh
haswell is bulldozer... - aigomorla
"DON'T BUY INTEL, they will send secret signals down the internet, which
will considerably slow down your computer". - SOFTengCOMPelec
VirtualLarry is offline   Reply With Quote
Old 12-29-2012, 11:20 AM   #4
Centauri
Golden Member

Centauri's Avatar

Join Date: Dec 2002
Location: Tucson, AZ
Posts: 1,439
Default

I doubt the CPU weighs enough to bend pins by bouncing around.
__________________
AMD A10-7850K APU ~ Radeon R7 IGP/8GBs of Patriot Viper 3 1866
128GB Samsung 830 SSD/2x 4TB Seagate DM000s/Gigabyte GA-F2A88XM-D3H
Antec EA-380D/Fractal Design Core 1000/Windows 8.1 Pro/Netgear Nighthawk
Centauri is offline   Reply With Quote
Old 12-29-2012, 11:34 AM   #5
Idontcare
Administrator
Elite Member

Idontcare's Avatar

Join Date: Oct 1999
Location: 台北市
Posts: 20,560
Default

Quote:
Originally Posted by Soulkeeper View Post

I delidded all those 3870's and overclocked them (cept 1 which I broke)

seems they all overclock nearly exactly the same
Did you notice any pre vs. post delidding improvements? Cooler temps, higher OC's, lower power usage, etc? Just curious what kind of dividends you reaped from your efforts.

Quote:
Originally Posted by VirtualLarry View Post
that sounds like it could be dangerous to the pins during rough shipping.
My FX-8350 cpu came in basically the same type of cpu retaining clear plastic clamshell as my Intel 2600k and 3770k. Pins were fine, the cpu is really well immobilized by the package.

In handling the FX-8350 I had no cause for concern that the pins might get damaged. AMD knows what it is doing.
Idontcare is offline   Reply With Quote
Old 12-29-2012, 04:02 PM   #6
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Default

Quote:
Originally Posted by Idontcare View Post
Did you notice any pre vs. post delidding improvements? Cooler temps, higher OC's, lower power usage, etc? Just curious what kind of dividends you reaped from your efforts.



My FX-8350 cpu came in basically the same type of cpu retaining clear plastic clamshell as my Intel 2600k and 3770k. Pins were fine, the cpu is really well immobilized by the package.

In handling the FX-8350 I had no cause for concern that the pins might get damaged. AMD knows what it is doing.
I only noticed a few C lower temps, no higher overclocks.
I was read thru this and am starting to think the motherboard (or possibly any fm1 board) is just not up to the task over high overclocks. I can't help but also consider there might be a flaw in the whole fm1 design, possibly part of the reason they jumped to fm2 so fast.
I had to put scotch tape over the SMDs because there is maybe 1mm of space between them and the heatsink after removing the IHS, could possibly contact and short if the heatsink is heavy or pushed on.

I also noticed that the capacitors have different colors from llano to llano, as if they individually choose them. Also the default voltage for CPU/NB varies and is lower in the newest ones (1.4v core vs. 1.4125v).
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org

Last edited by Soulkeeper; 12-29-2012 at 04:13 PM.
Soulkeeper is offline   Reply With Quote
Old 12-29-2012, 04:07 PM   #7
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Default

Quote:
Originally Posted by ShadowVVL View Post
someone loves llano

lol photo reminds me of the setup in my old appartment with the box spring and mattress on the floor.

Any plans on getting trinity? or is there no delidding trinity?
No plans to get trinity, my next system will support ecc memory, more than 4 cores, and more than 4MB of cache. I'm hoping I can hold out for steam roller or even ddr4 just to see what AMD's next platform does. If I had to do it all over again i'd have gone socket 1155 or am3+.
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org
Soulkeeper is offline   Reply With Quote
Old 01-24-2013, 09:55 AM   #8
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Default

I purchased another fm1 motherboard off the discount rack at the local fry's (my 4th fm1 board). The GA-A75M-UD2H died on me after a week of instability and problems booting it stopped seeing hard drives.

F1A75-V Pro
6+2 vrm likely the board I should have gotten in the first place.
It supports the samsung 30nm mem (GA-A75M-UD2H did not).
Amazing throttling ability for low power use, stable as a brick.
The only downside is the northbridge freq is locked so it's about 5% slower than the gigabyte board at the same clocks/settings.
Also it appears asus automatically sets the nb div by mem speed as per the following table I worked out. So with my chip only able to do about 800MHz nb that limits me to the lowest mem speed of 1064.
Chart of FM1 clocks
Almost certainly mapping 6.0 to 4.0 and advancing in lockstep.

Also the sata stops working at 133bclk, like all the other fm1 boards, (the asmedia chip likely works, but I didn't try it). So just like the other 3 fm1 boards 133bclk is a pipe dream.

This should tide me over untill haswell or further
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org

Last edited by Soulkeeper; 01-24-2013 at 10:12 AM.
Soulkeeper is offline   Reply With Quote
Old 01-24-2013, 10:01 AM   #9
sm625
Diamond Member

sm625's Avatar

Join Date: May 2011
Posts: 4,972
Default

So you delidded 5 cpu's, broke one, then posted a picture of the boxes. Tell me what sense is there in any of this? Why risk 20% damages? Instead of buying 5 and breaking one, why not just buy 4 intel and not mess with them?
__________________
I am looking for a cheap upgrade to my 3 year old computer.
AT forum member #1: Buy a 4790k

I am looking for a way to get 10 more fps in TF2.
AT forum member #2: Buy a 4790k
sm625 is online now   Reply With Quote
Old 01-24-2013, 10:15 AM   #10
Haserath
Senior Member

Join Date: Sep 2010
Posts: 750
Default

Quote:
Originally Posted by sm625 View Post
So you delidded 5 cpu's, broke one, then posted a picture of the boxes. Tell me what sense is there in any of this? Why risk 20% damages? Instead of buying 5 and breaking one, why not just buy 4 intel and not mess with them?
And you call yourself an 'enthusiast'.
Haserath is offline   Reply With Quote
Old 01-24-2013, 11:49 AM   #11
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Default

Quote:
Originally Posted by sm625 View Post
So you delidded 5 cpu's, broke one, then posted a picture of the boxes. Tell me what sense is there in any of this? Why risk 20% damages? Instead of buying 5 and breaking one, why not just buy 4 intel and not mess with them?
Chances are i'd delid the intels too ...
the ivy bridges lack SMD caps under the IHS so it'd be easier.
It's not fun unless I push the limits.
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org
Soulkeeper is offline   Reply With Quote
Old 01-24-2013, 12:47 PM   #12
sm625
Diamond Member

sm625's Avatar

Join Date: May 2011
Posts: 4,972
Default

Quote:
Originally Posted by Haserath View Post
And you call yourself an 'enthusiast'.
Well.... I might shake my head at this whole endeavor but I still want to see pics. It was the pics of nothing but boxes that made me
__________________
I am looking for a cheap upgrade to my 3 year old computer.
AT forum member #1: Buy a 4790k

I am looking for a way to get 10 more fps in TF2.
AT forum member #2: Buy a 4790k
sm625 is online now   Reply With Quote
Old 01-24-2013, 03:54 PM   #13
Shellls
Junior Member

Shellls's Avatar

Join Date: Jan 2013
Location: Boston area
Posts: 6
Default

I think it your MOBO was the problem. My early production 3850 got 3.5 ghz on stock voltage on my A75m-UD2H.
Shellls is offline   Reply With Quote
Old 01-24-2013, 04:27 PM   #14
Phynaz
Diamond Member

Phynaz's Avatar

Join Date: Mar 2006
Posts: 6,770
Default

Quote:
Originally Posted by sm625 View Post
So you delidded 5 cpu's, broke one, then posted a picture of the boxes. Tell me what sense is there in any of this? Why risk 20% damages? Instead of buying 5 and breaking one, why not just buy 4 intel and not mess with them?
Dude, chill.
Phynaz is offline   Reply With Quote
Old 01-24-2013, 05:08 PM   #15
frozentundra123456
Diamond Member

Join Date: Aug 2008
Posts: 5,734
Default

Quote:
Originally Posted by Haserath View Post
And you call yourself an 'enthusiast'.
You have a point I guess, but to me there are 2 kinds of 'enthusiasts". One insists on tinkering and trying to get the most out of a lower performing part, and the one who just want to buy the best part to begin with. The first would be fun, but I am not very mechanically inclined, so it does not appeal to me. I would still consider myself an enthusiast though, simply because I am very interested in PC performance and gaming, and read everything I can lay my hands on about the topic.
frozentundra123456 is online now   Reply With Quote
Old 01-24-2013, 05:41 PM   #16
Centauri
Golden Member

Centauri's Avatar

Join Date: Dec 2002
Location: Tucson, AZ
Posts: 1,439
Default

I believe the term which would apply to a nerd who's scared of tinkering is Armchair Enthusiast.
__________________
AMD A10-7850K APU ~ Radeon R7 IGP/8GBs of Patriot Viper 3 1866
128GB Samsung 830 SSD/2x 4TB Seagate DM000s/Gigabyte GA-F2A88XM-D3H
Antec EA-380D/Fractal Design Core 1000/Windows 8.1 Pro/Netgear Nighthawk
Centauri is offline   Reply With Quote
Old 01-24-2013, 06:38 PM   #17
Idontcare
Administrator
Elite Member

Idontcare's Avatar

Join Date: Oct 1999
Location: 台北市
Posts: 20,560
Default

Quote:
Originally Posted by Centauri View Post
I believe the term which would apply to a nerd who's scared of tinkering is Armchair Enthusiast.
Are we so plentiful in numbers for our demographic that we have the luxury of further segmenting ourselves into denigrating sub-categories?

This stuff makes no sense to me, and not trying to pick on you. We see it all the time with the epeen quips for people who like to buy expensive hardware too.

To what end? What possible purpose is served in belittling or labeling our fellow enthusiasts with unflattering terms?

Our demographic is diverse, true, and none of us are going to identify ourselves with each and every aspect of the genre. But that is cause to celebrate how far (and accepted) our genre has come, not a reason to point and laugh at the people we might feel are the fringe elements of it.
Idontcare is offline   Reply With Quote
Old 01-24-2013, 06:58 PM   #18
Jen
Elite Member

Jen's Avatar

Join Date: Dec 1999
Posts: 24,112
Default

my fm1 asus mini itx board would do 133 fsb as long as sata mode was set to ide . i think max was 137 fsb before things got strange so i just used it at 133 fsb


Jen
__________________
Heatware
everyday is a adventure , never knowing where your going or where you been

Wanted
2.5 laptop drive 2TB
Jen is offline   Reply With Quote
Old 01-24-2013, 07:07 PM   #19
spartan805
Member

spartan805's Avatar

Join Date: Apr 2007
Location: Southern California
Posts: 36
Default

Trying to get into LLANO, i just picked up an A6-3650
spartan805 is offline   Reply With Quote
Old 01-29-2013, 03:01 PM   #20
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Default

3.5GHz 1.391v - stable
3.6GHz 1.391v - unstable
3.6GHz 1.404v - unstable
3.6GHz 1.416v - stable

actual volts is -0.009 from what's set, not worth changing the vrm freq when I can just lift the voltage .0125
1.4125v is the max/default according to AMD, so this is excellent.

I got 3.6GHz stable
good motherboard/vrm makes all the difference as I had suspected
Maybe i'll try for more later.
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org
Soulkeeper is offline   Reply With Quote
Old 01-29-2013, 06:47 PM   #21
ctsoth
Member

Join Date: Feb 2011
Posts: 118
Default

Quote:
Originally Posted by Soulkeeper View Post
3.5GHz 1.391v - stable
3.6GHz 1.391v - unstable
3.6GHz 1.404v - unstable
3.6GHz 1.416v - stable

actual volts is -0.009 from what's set, not worth changing the vrm freq when I can just lift the voltage .0125
1.4125v is the max/default according to AMD, so this is excellent.

I got 3.6GHz stable
good motherboard/vrm makes all the difference as I had suspected
Maybe i'll try for more later.
That is an excellent overclock at that voltage. I've gone up to 1.6v in the past and my 3870k will not run stable at 3.6.

I have f1-a75pro/csm. I don't know what the 'csm' bit stands for.
ctsoth is offline   Reply With Quote
Old 01-29-2013, 09:07 PM   #22
Soulkeeper
Diamond Member

Soulkeeper's Avatar

Join Date: Nov 2001
Posts: 5,957
Default

Quote:
Originally Posted by ctsoth View Post
That is an excellent overclock at that voltage. I've gone up to 1.6v in the past and my 3870k will not run stable at 3.6.

I have f1-a75pro/csm. I don't know what the 'csm' bit stands for.
csm are office oriented, they underclock the memory controller 1 step for stability
identical otherwise
"Corporate Stable Model"

F1A75-M Pro is 4+2 vrm
Just like others, with that many phases or less, this seems to keep the quad llanos capped around 3.3-3.5GHz
Also I noticed a feature in the asus bios for cpu/nb "current capability", from what I gather there is a hard wall related to the over current protection and this must be raised or system will just not manage higher clocks.
__________________
A8-3870 @3.3GHz 1.3125v
16GB 1866 9-9-9-23 1t 1.35v
Linux software/gaming exclusively
linuxsociety.org

Last edited by Soulkeeper; 01-29-2013 at 09:24 PM.
Soulkeeper is offline   Reply With Quote
Reply

Thread Tools

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off

Forum Jump


All times are GMT -5. The time now is 09:28 AM.


Powered by vBulletin® Version 3.8.7
Copyright ©2000 - 2014, vBulletin Solutions, Inc.
